DTP Qatar - Compiled from Howen quotations (17 Jul 2026), proforma invoice HNHW260727012-PI02 (27 Jul 2026), the Howen 2026 company presentation, and product datasheets.
78 line items across 6 product categories plus archive, 17 with confirmed pricing, the rest under RFQ.
Last built: .
VSS demo: granted - demo account + guidance videos received. (Was refused for weeks; conceded after the 2 Aug pressure email + call to Jack.)
CE certification: certificate received (RED 2014/53/EU, HK2207062913E, Aug 2022) covering ME40-01..04, MC30-01..04 and MA90-01..04 dashcams. Note: the BC03 bodycam is NOT on it.
Correct datasheets: received for the actually-quoted cameras - V40 IP (85°, IP68, 168g - not wide-angle as assumed), V16 IP (IP68, 258g), C60S0V4 AHD (IP67, 18 IR LEDs).
Full price list: declined - Howen doesn't maintain one; they quote complete solutions per project. Consequence: our RFQ must be a concrete configuration (the kit builder output), not a catalogue request.
Sensors (slide 26): Door, Temp & Humidity, OBD/CANBUS and RFID readers sold directly by Howen; fuel-level and weight sensors are partner brands sourced separately.
Lead time / stock: sample prep ~1 week (PI's 15 working days is the maximum); some PI items in UAE stock for fast testing purchase, rest from China.
Sample pricing: "will do our best to apply special pricing support" once order + quantities confirmed - still not a number.
Still open
Ignored in the 3 Aug reply: MDT production-resume timeline (their #6), evaluation/licensing units on loan or at-cost (#7), volume pricing tiers at 1k/5k/10k/25k (#10), Qatar territory & channel protection (#11). Re-raise all four.
NDA: they asked for our template - send it. Nothing else proceeds unsigned.
FCC certification (CRA simplified type-approval can use CE or FCC - CE now in hand, FCC status unknown) and BC03 bodycam certification of any kind.
MA90 series: appears on the CE certificate but nowhere in any quote, presentation or the website - what is it?
UAE stock: exact list of PI items available from the UAE reseller, prices, and the reseller contact Rocket offered.
PoN switches: anything bigger than the 3-channel PON03? Can PON03s be stacked/daisy-chained, and can they hang off a DVR/NVR rather than only a dashcam?
AVM output: AHD/CVBS/HDMI only per spec - is there an IP-output variant?
IP PTZ: none in the range - available/planned, or justification for AHD PTZ + AVM in an otherwise-IP system?
Pillar camera: housing dimensions + mounting drawings for V16 / V29 / V30 dome (custom in-pillar bracket will be fabricated). Any flush/pinhole camera not on the website?
Water ratings: still unconfirmed for V26 IP, V30/V10 IP domes, AVM exterior cameras, PON03, cables, BC03. (V16/V40 IP68 and V4 IP67 now confirmed.)
Marine use: ME41-02M on jetskis (salt/spray/vibration)? MC30/ME40 in boat cabins (humidity)?
ME35 MNVR: 4G (hard requirement) and storage type/capacity.
Recorder channel splits: confirm AHD/IP splits for ME32-06, ME31-12, ME31-16 (currently assumed in our kit builder).
VSS licensing: per camera/channel or per device? One-time or recurring?
BC03 storage: SD-card version or customization for removable storage? And storage media generally: include SD/SSD/HDD options and capacities in solution quotes, or do we source separately?
Remaining detail: C60S0V3 pricing (datasheet sent 19 Jul, never priced), S vs H suffix meaning, OBD reader vs CANBUS license overlap, AI license bundled-free confirmation at volume, AVM recommended recorder pairing, BSD vs Hands-Off-Detection mutual exclusivity scope.
Build a Kit
SKU / Model Code
Product
Description
Unit Price
Qty
Line Total
Main Cameras (Dashcam Units) (8)
The front dual-camera units every kit starts with - AI dashcams with built-in road + cabin views, 4G, GPS. One per vehicle.
Hero-MC30-02 H
Quote 17 Jul + PI
MC30-02 H Dashcam Bundle
The base dashcam unit for cars, vans and taxis. Two cameras are built in (front + in-cab), and it takes one IP camera natively, expandable to three external IP cameras total once you add a PoN switch (below). Compare to the ME40-02: this is the lighter, cheaper tier, with no RS232 port and only 1 TF card slot instead of 2. Buy this for cars, taxis and light patrol vehicles; move to the ME40-02 if the vehicle needs RS232 peripherals, a dedicated AHD camera channel, or more onboard storage. Water rating: none published - in-cab unit; boat-cabin/marine use is an open Howen question. CE certified (RED 2014/53/EU, cert HK2207062913E, received 3 Aug - covers the MC30-01..04, ME40-01..04 and MA90 series; the BC03 bodycam is NOT on this certificate).
$125
per set
—
Hero-ME40-02
Quote 17 Jul + PI
ME40-02 V8 Pro Dashcam
The heavy-duty recorder for trucks and logistics vehicles, one tier up from the MC30-02H. Per Howen's datasheet it supports 4 external cameras total: exactly 1 AHD (analog) camera plus up to 3 IP cameras (1 direct, 2 more via the PoN switch above), and adds an RS232 port, CANBUS, a built-in panic button, and 2 TF card slots instead of 1. Buy this for trucks and larger vehicles needing serial-peripheral integration, a dedicated analog camera channel, or more onboard storage; the MC30-02H is cheaper and enough for cars, vans and taxis that don't need those extras. Water rating: none published - in-cab unit; boat-cabin/marine use is an open Howen question. CE certified (RED 2014/53/EU, cert HK2207062913E, received 3 Aug - covers the MC30-01..04, ME40-01..04 and MA90 series; the BC03 bodycam is NOT on this certificate).
$210
per set
—
Hero-ME41-02 M
Datasheet 19 Jul
Motorcycle AI Dashcam/MDVR
The only motorcycle-specific unit Howen offers - a small waterproof (IP67) box with 2 built-in channels plus 2 external AHD cameras, using its own fixed 1.7m cable and a 4-pin BMW connector rather than the aviation cabling used everywhere else in this list. None of the extension cables above are compatible with it. Relevant only if the program includes motorcycle patrol units; irrelevant for cars, vans, trucks or buses. Water rating: IP67 confirmed - rain/splash proof; jetski use plausible, marine confirmation requested from Howen.
Request Quote
request quote
—
MC30-02 N2
Company Presentation 2026
Mini AI Dashcam (2+2ch)
Sits between the base MC30-01 tier and the already-priced MC30-02H: still an AI mini dashcam, but capped at 2 external cameras instead of 3. Only worth pursuing if a specific vehicle genuinely needs exactly 2 external cameras and the small cost saving matters; otherwise stick with the MC30-02H already negotiated, since going off-list resets pricing from zero. Water rating: none published - in-cab unit.
Request Quote
request quote
—
MC30-02 S
Company Presentation 2026
Mini AI Dashcam Variant (S-series)
Same relationship to the MC30-02H as the MC30-01S has to the MC30-01H above - an 'S' suffix variant of an already-priced model. Don't assume it's meaningfully different without asking Howen directly what the S/H distinction changes. Water rating: none published - in-cab unit.
Request Quote
request quote
—
ME40-02 V9
Company Presentation 2026
6ch AI Dashcam V9
An upgraded sibling of the already-quoted and priced ME40-02 V8 Pro, positioned for heavier logistics trucks with richer interfaces. Only worth investigating if a specific vehicle's wiring needs exceed the V8 Pro's 4 external camera ports, RS232, and single CANBUS; for everything already scoped, the V8 Pro already priced covers it. Water rating: none published - in-cab recorder.
Request Quote
request quote
—
MC30-01 H
Company Presentation 2026
Mini Eco-Dashcam (1+1ch)
A step down from the already-priced MC30-02H: fewer channels (1 built-in + 1 external, versus 2+3) and, going by the naming, likely no AI license bundled at all. Only worth considering for a bare-bones, recording-only unit with no face/DMS/ADAS requirement - which conflicts with the AI-heavy scope already discussed for this deployment, so treat this as an unlikely fit.
Request Quote
request quote
—
MC30-01 S
Company Presentation 2026
Mini Dashcam Variant (S-series)
Listed alongside the MC30-01H as an 'S' variant. Howen's naming typically uses S/H suffixes for hardware or cost variants of the same tier rather than a different feature set. Don't treat this as a separate purchasing option until Howen confirms exactly what differs from the H version - it may just be a factory SKU variant, not a real choice.
Request Quote
request quote
—
Side / Rear / Front / Cabin Cameras (16)
View cameras for every mounting position, both families: IP (C62, 6-pin) and AHD (C60, 4-pin). Priced items carry their quoted price; the rest are RFQ.
Hero-C62S0V40-2MR
Quote 17 Jul + PI
V40 Rear View IPC Camera
Rear-facing IP camera - datasheet received 3 Aug corrects earlier assumptions: standard 85° horizontal view with a 3.6mm lens (NOT wide-angle - the 175° V40 is the AHD version only). Electrically identical to the V16 side camera (2MP 1/3" CMOS, H.264/H.265, ONVIF, 11 IR LEDs to 5m, 6-pin M12 aviation connector), in a compact 168g rear housing. Part of the PI-validated combo Howen recommends for guaranteed compatibility (V40 + V16 + C60S0V4). Water rating: IP68 confirmed by datasheet. Operating -20 to +70°C.
$22
per camera
—
Hero-C62S0V16-2MR
Quote 17 Jul + PI
V16 Side View IPC Camera (Eco)
Same IP camera family as the V40 above, in a side-facing housing, marketed as the cost-reduced 'Eco' tier. Confirmed by datasheet: 2MP, 3.6mm lens, 85 degree horizontal field of view, H.264/H.265, ONVIF support, 6-pin M12 aviation female connector, IP68. Use it for side or blind-spot coverage; it shares cabling and recorder-slot type with the V40, so the choice between the two is purely about where on the vehicle the lens points. Water rating: IP68 (datasheet-confirmed). Full datasheet re-confirmed 3 Aug: 258g, 11 IR LEDs to 5m, -20 to +70°C, part of the PI-validated combo.
$22
per camera
—
Hero-C60S0V4-2MR
Quote 17 Jul + PI
V4 Rear View AHD Camera
An analog (AHD) camera, not an IP camera - this family outputs raw analog video over a 4-pin aviation connector rather than compressed digital video, and needs its own dedicated analog decoder channel on the recorder instead of a shared, expandable IP port. That's exactly why the ME40-02 only ever fits one of these: its single AHD channel is fixed in hardware, unlike the IP cameras above, which multiply with a PoN switch. Use this for the ME40-02's one AHD slot (typically the rear view); don't confuse it with the C62 IP cameras above, which use a different cable family entirely (6-pin, not 4-pin). Datasheet received 3 Aug: 18 IR LEDs, 1MP/2MP variants, 0.3kg, -20 to +70°C, part of the PI-validated combo. Water rating: IP67 confirmed.
$20
per camera
—
Hero-C62S0V26-2MR
howentech.com Aug 2026
Rear View IP Camera (Metal)
The metal-cased rear IP camera, sibling of the plastic V40 wide-angle already priced. Same 6-pin IP family (2MP, 12 IR LEDs, 3.6mm lens, 90 degree view), tougher housing for exposed rear mounting. Choose between this and the V40 by housing and view width: V40 gives a 175 degree panorama in plastic; this gives a standard 90 degree view in metal. Not in any quote yet - needs pricing from Howen. Water rating: unconfirmed for the IP variant (AHD twin is IP67/IP68) - ask Howen.
Request quote
—
Hero-C60S0V3-1MR/2MR
Datasheet 19 Jul
C60S0V3 AHD Side View Camera
The side-mounted sibling of the V4 rear camera above, same AHD family (analog, 4-pin aviation connector, no audio). Howen sent a datasheet for this exact side variant on 19 Jul, but every quote and the PI since then have only priced the V4 rear camera - so if an AHD camera pointed sideways is actually wanted (as opposed to the already-priced IP side camera, C62S0V16), Howen needs to be asked directly to price this SKU; it isn't in any total yet.
Request Quote
request quote
—
Hero-C60S0V42-1MR2/2MR2
howentech.com Aug 2026
Dual-Lens AHD Camera
Two lenses in one mini housing - covers two directions from a single AHD channel and mount point (e.g. front + in-cab from the windshield). 720P/1080P, 5 IR LEDs, audio with built-in mic, 4-pin aviation cable, 3M sticker mount. Water rating: not published (interior-style unit) - ask Howen.
Request quote
—
Hero-C60S0V29-2MR
howentech.com Aug 2026
Mini In-Cab AHD Camera
The smallest in-cab view camera in the range - 1080P, wide-angle, 3M sticker mount, designed to pair with dashcams. A strong candidate for the pillar rear-cabin view if going AHD: tiny, sticker/bracket mounted, 4-pin aviation cable. Water rating: not published (interior unit).
Request quote
—
Hero-C60S0V42F-1M/2M/1MS
howentech.com Aug 2026
Front View AHD Camera (Tilt)
Windshield-mounted forward camera with tilt adjustment and built-in mic, 720P/1080P, 3.6mm lens (2.1mm optional for wider view). For adding a forward channel to an MDVR without using a dashcam. Water rating: not published (interior mount).
Request quote
—
Hero-C60S0V42R-1MR/2MR
howentech.com Aug 2026
In-Cab View AHD Camera
Cabin-facing counterpart of the V42F - 720P/1080P, low illumination capable. Driver/cabin coverage on a plain MDVR channel. Water rating: not published (interior unit).
Request quote
—
Hero-C60S0V24-1M/2M
howentech.com Aug 2026
Front View AHD Camera (Metal)
Metal-cased forward camera, 720P, 12 IR LEDs, highlight compensation for headlight glare. Water rating: not published - metal case suggests exterior duty, ask Howen.
Request quote
—
Hero-C60S0V26-1MR/1MS/2MR
howentech.com Aug 2026
Starlight Rear View AHD Camera
The AHD twin of the V26 IP rear camera - same adjustable U-bracket + visor mounting that aims correctly on any surface. 720P/960P/1080P, starlight low-light option (1MS), metal case, pan/tilt. Water rating: IP67/IP68 confirmed.
Request quote
—
Hero-C60S0V37-1MR
howentech.com Aug 2026
Mini Rear View AHD Camera
Smaller, cheaper rear camera - 720P, metal case, 12 IR LEDs, pan/tilt adjustment. Water rating: IP67 confirmed.
Request quote
—
Hero-C60S0V36-1MR/2MR
howentech.com Aug 2026
Side View AHD Camera (V36)
Metal-cased side camera, 720P/1080P, 12 IR LEDs, highlight compensation. Water rating: IP67 confirmed.
Request quote
—
Hero-C60S0V36-1MS
howentech.com Aug 2026
Starlight Side View AHD Camera
The V36 with a starlight sensor - 0.01 lux, usable in near-darkness without IR glow. Water rating: IP67/IP68 confirmed.
Request quote
—
Hero-C60S0V39-1MR/2MR
howentech.com Aug 2026
Mini Side AHD Camera
Smallest side camera - 720P/1080P, 5 IR LEDs, pan/tilt, works with IR at 0 lux. Water rating: IP65 confirmed.
Request quote
—
Hero-C60S0V40-1MR/2MR
howentech.com Aug 2026
Wide-Angle AHD Camera (175°)
The AHD twin of the V40 IP wide-angle - same 1.6mm 175 degree panorama, 8 IR LEDs. Water rating: IP67/IP68 confirmed.
Request quote
—
Special Cameras (Domes, PTZ, AI, AVM, Bodycam) (16)
Interior domes, the operator-steerable PTZ, standalone DMS/ADAS/BSD AI cameras, the 360° AVM surround kit, explosion-proof housing, and body-worn cameras.
Hero-BC03-A464
Quote 17 Jul + PI
BC03 Bodycam (64GB)
A body-worn camera for an officer or inspector, unrelated to the vehicle dashcam/MDVR system and cabling above. Front lens (120 degree field of view) plus a second rear-facing lens (56.8 degree), 2K/1080p/720p recording, 4G/WiFi/GPS/Bluetooth, touchscreen, roughly a full shift's battery life (3050mAh). This is the smallest of four identical units below that differ only in storage: 64GB. Pick capacity by how long footage sits before being offloaded - 64GB suits a daily-download workflow; for longer stretches without a download, go up a tier. Water rating: not published - body-worn use implies splash resistance, but confirming with Howen.
$255
per unit
—
Hero-BC03-A4128
Quote 17 Jul (bodycam)
BC03 Bodycam (128GB)
Identical hardware to the 64GB unit above - same lenses, battery, connectivity. The only difference across all four BC03 capacities is storage. 128GB roughly doubles the recording time before an offload is needed, for about $23 more per unit than the 64GB tier. Water rating: not published - confirming with Howen.
$278
per unit
—
Hero-BC03-A4256
Quote 17 Jul (bodycam)
BC03 Bodycam (256GB)
Identical hardware to the other BC03 capacities above. This is the mid-upper storage tier - worth the step up from 128GB if officers routinely go multiple shifts between downloads. Water rating: not published - confirming with Howen.
$311
per unit
—
Hero-BC03-A4512
Quote 17 Jul (bodycam)
BC03 Bodycam (512GB)
Identical hardware to the other BC03 capacities above. The largest storage tier, for continuous-wear use with the least-frequent offloading. If daily downloads are already part of the workflow, the 64GB or 128GB units save money without losing anything else. Water rating: not published - confirming with Howen.
$367
per unit
—
Hero-C62S0V30-2MR
howentech.com Aug 2026
Mini IR Dome IP Camera
The smallest dome in the IP family - ceiling or pillar mount, pan/tilt adjustable, 2MP, IR for darkness, 6-pin aviation connector, PoN support. This is the pick for the pillar-mounted rear-cabin view in cars and for interior ceiling coverage in vans and buses when standardizing on IP. Not in any quote yet. Water rating: unconfirmed - ask Howen.
Request quote
—
Hero-C62S0V10-2MR
howentech.com Aug 2026
Fisheye IR Dome IP Camera
A 170 degree fisheye dome in the IP family - one ceiling unit can cover an entire small cabin on its own, replacing two conventional interior cameras. 2MP, 18 IR LEDs, pan/tilt, 6-pin aviation connector, PoN support. The alternative to the V30 dome when maximum coverage per channel matters more than a natural-perspective image. Not in any quote yet. Water rating: unconfirmed - ask Howen.
Request quote
—
Hero-SD10-XVA5/XVA6
howentech.com Aug 2026
PTZ AHD Camera (360 Pan/Tilt)
A motorized pan-tilt-zoom camera an operator can steer remotely - 360 degree pan, tilt, 128 presets, cruise routes, 0.001 lux night capability, IP66 aluminum housing, IR to 50-80m on the XVA6. Kept despite being AHD because no IP equivalent exists in Howen's range: it needs an RS485 control line plus an AHD channel, which the ME31/ME41 MDVRs provide. For command/security vehicles where dispatch actively looks around a scene. Not in any quote yet. Water rating: IP66 (rain-proof, aluminum housing).
Request quote
—
Hero-C60S0D5-1MR
howentech.com Aug 2026
DMS Camera (D5)
Driver-monitoring camera, 720P black-and-white optimized for face analysis, 0.1 lux, 2m fixed cable. Feeds the recorder's DMS AI. Only needed on recorders without a built-in DMS lens. Water rating: not published (interior unit).
Request quote
—
Hero-C60S0D6-1MR
howentech.com Aug 2026
DMS Camera (D6, A-Pillar)
Same DMS job as the D5 but shaped specifically for A-pillar installation - relevant to the pillar-mount concept. 720P B&W, 6mm lens, WDR, 2m cable. Water rating: not published (interior unit).
Request quote
—
Hero-C60S0V61-2MR
howentech.com Aug 2026
Mini IR Dome AHD Camera
Compact interior dome (71.6 x 64 x 40.3mm - dimensions actually published), 1080P, pan/tilt adjustment, audio, lens options 3.6/2.8/2.1mm for 90-120 degree view. The AHD counterpart of the V30 IP dome. Water rating: not published - ask Howen.
Request quote
—
Hero-C60S0V5-1MR/2MR
howentech.com Aug 2026
Mini Dome AHD Camera
Interior mini dome, 720P/1080P, 12 IR LEDs, day/night mode, optional audio, lens options to 120 degrees. Bus/van ceiling workhorse. Water rating: not published - ask Howen.
Request quote
—
Hero-C60S0V6-1MR/2MR
howentech.com Aug 2026
IP67 Dome AHD Camera
In-ceiling dome rated IP67 - the dome to use where water is real (open vehicles, washdown areas, marine candidates). 720P/1080P, 10 IR LEDs, 0.01 lux. Water rating: IP67 confirmed.
Request quote
—
Hero-C60S0V30-2MR
howentech.com Aug 2026
Vehicle AHD IR Dome (V30)
Mini IR dome, 1080P, pan/tilt, audio, lens options to 120 degrees. Water rating: IP65 confirmed - splash/rain resistant.
Request quote
—
Hero-C60S0V25-1ME
howentech.com Aug 2026
Explosion-Proof AHD Camera
Vandal-proof to IK10 with 304 stainless cable, 960P, 0.01 lux - for oil & gas zones, prisoner transport, or anywhere the camera itself may be attacked. Water rating: IP67/IP68 confirmed.
Request quote
—
360° AVM System
Company Presentation 2026
4-Camera Surround View
A parking/maneuvering aid, not a security feature - it stitches 4 cameras into one bird's-eye view around the vehicle, the same idea as a car's 360 degree backup camera system. Useful for large buses or trucks maneuvering in tight spaces; irrelevant to the program's core evidentiary-recording and driver-monitoring goals, so weigh it as a nice-to-have, not a requirement. Water rating of the 4 exterior cameras: unconfirmed - ask Howen (they live outside in rain/spray).
Request Quote
request quote
—
BSD Camera
Company Presentation 2026
Blind Spot Detection Camera
A dedicated blind-spot camera for the regulatory-style BSD/BSIS alerting the ME40-02's datasheet lists as an optional feature (note: BSD and the recorder's 'Hands Off Detection' feature are mutually exclusive - one or the other, not both). Relevant for buses or trucks where blind-spot alerting is a safety requirement; not needed for cars or light vehicles. Water rating: unconfirmed - exterior mount, ask Howen.
Request Quote
request quote
—
Cables & Wiring (5)
Adapter cables, extensions and power harnesses. Note: documented SKUs cover the dashcams; recorder-side camera cabling is an open RFQ question.
HW-DJC-6B6N-5
Quote 17 Jul + PI
BMW-to-Aviation Ext. Cable (5m)
The adapter cable that bridges the recorder's own multi-pin socket (a locking round-pin design the industry calls a 'BMW connector', unrelated to the car brand) to the aviation-connector standard the IP cameras use, 5 metres long. You need at least one of these for every external camera run - it's what plugs into the recorder itself. Different from the IP Camera Ext. Cable below: this one changes connector type; that one doesn't. Water rating: connectors are locking aviation type; formal IP rating unconfirmed - ask Howen.
$4
per cable
—
HW-DJC-5N
Quote 17 Jul + PI
IP Camera Ext. Cable (5m)
A pure extension cable for the aviation-connector side of the run - male to female, 6-pin (matching the IP camera family: the C62 side/rear cameras above), 5 metres. Chain it onto the BMW-to-Aviation cable only if 5m isn't enough to reach the camera's mounting point, e.g. the back of a longer vehicle; skip it for cars or vans where the first cable already reaches. Water rating: aviation connectors; formal IP rating unconfirmed - ask Howen.
$4
per cable
—
HW-IO-8P4P3P
Quote 17 Jul + PI
Ext. Cable Set (ME40-02)
Not a camera cable - this is the ME40-02's main power/ignition wiring harness, breaking the recorder's 8-pin power port out to a 4-pin connector plus 3 loose wires (ignition, battery, ground) and a short secondary 4-pin cable. One of these is required for every ME40-02 install regardless of how many cameras are attached; it's unrelated to the DJC/IPC camera cables above. Water rating: interior harness; no rating published.
$3
per set
—
HW-IPC-10P6P4P
PI 27 Jul
Ext. Cable (ME40-02, 2.5m)
The ME40-02's version of the BMW-to-Aviation cable above - the first-leg adapter from the recorder's port down to the aviation-connector standard, just with a different pin arrangement (10-pin to 4-pin+6-pin) because the ME40-02 uses a different onboard connector than the MC30-02H. It's shorter (2.5m); add the 5m or 9m extension cables above if the camera sits further away. Water rating: aviation connectors; formal IP rating unconfirmed - ask Howen.
$6
per cable
—
HW-DJC-9
PI 27 Jul
Aviation Ext. Cable (9m)
A 4-pin extension cable, longer (9m) than the 6-pin IP Camera Ext. Cable above. The pin count tracks which camera family it serves: 4-pin fits the AHD camera (C60 series, above), 6-pin fits the IP cameras (C62 series). Buy this only if the AHD rear camera needs to reach 9m from the recorder - a long bus or truck chassis, for example; for cars, the shorter cables above are already enough.
$6
per cable
—
DVRs / NVRs / Switches (12)
Recorders smallest to biggest - SD-card MDVRs, SSD/HDD units, IP-only MNVRs, hybrids - plus the PON03 switch. External cameras land here, not on the dashcam.
Hero-PON03
PI 27 Jul
PoN Switch (3ch)
A small hub for the IP-camera side of the system. Howen's own spec sheet for the ME40-02 confirms it natively takes only 1 IP camera directly and 'supports PoN switch to add 3 IPC' - so the recorder's single AHD channel is fixed in hardware, but its IP camera capacity is expandable, and this switch is what does the expanding, similar in role to a small PoE switch on an office network. Buy exactly one per vehicle needing more than one IP camera (e.g. side + side + rear coverage); skip it if only a single IP camera is needed, since that plugs in directly without a switch. Water rating: unconfirmed - ask Howen (mounts hidden, but boats/washdowns make it relevant).
$26
per switch
—
Hero-ME40-04 N3
Datasheet 19 Jul
4ch Economical AI MDVR (Bus/Truck)
A cheaper 4-channel recorder, but architecturally different from the ME40-02 above: per its own datasheet, all 4 of its camera inputs are AHD (analog) - there's no IP-camera port and no PoN switch support at all. That matters because the IP cameras already priced (C62 V16/V40) would not plug into this unit. A reasonable fit only if a vehicle is being wired entirely with analog cameras from scratch; if the fleet is standardizing on the IP camera family already quoted, look at the ME35 series (IP-based MNVR, below) instead.
Request Quote
request quote
—
ME41-04
Company Presentation 2026
4ch AI Dashcam/MDVR
A genuine step up in class from the motorcycle-only ME41-02M and the mini MC-series dashcams: proper 4-channel MDVR territory, with CANBUS library support and Ethernet networking built in, rather than the vehicle-port aviation cabling used on the dashcam-tier units. Relevant for a vehicle needing four simultaneous camera views with full network/CAN integration, but not truck-scale enough to need the bigger ME32/ME31 units below. Water rating: none published - in-cab recorder.
Request Quote
request quote
—
ME32-04
Company Presentation 2026
4ch AI MDVR
A heavier-duty 4-channel MDVR than the ME41-04 above, aimed at buses and trucks rather than cars. Choose between this and the ME32-06 below purely by camera count - 4 versus 6 - not by any other confirmed feature difference. Water rating: none published - in-cab recorder.
Request Quote
request quote
—
ME32-06
Company Presentation 2026
6ch AI MDVR
Same MDVR tier as the ME32-04 above, with 2 more camera channels. Pick this over the 04 variant only if the vehicle genuinely needs 6 simultaneous camera views (e.g. a bus with front, rear, both sides, door, and cabin coverage); otherwise the 4-channel version is the cheaper fit. Water rating: none published - in-cab recorder.
Request Quote
request quote
—
ME31-08 V5
Company Presentation 2026
8ch AI MDVR
The next step up in channel count from the ME32 pair above, for large buses or trailer-trucks needing more than 6 camera views. Skip it unless a vehicle genuinely has more than 6 camera positions to cover - it's overkill, and presumably priced accordingly, for standard patrol cars or vans. Water rating: none published - in-cab recorder.
Request Quote
request quote
—
ME31-12
Company Presentation 2026
AI MDT / 12ch Platform
One of the largest-channel recorders in Howen's range, grouped with the MDT dispatch tablets and the ME31-08 in the product line grid. Realistically only relevant for the biggest vehicles in a fleet - large buses, command vehicles - wanting near-total camera coverage; substantial overkill for anything smaller. Water rating: none published - in-cab recorder.
Request Quote
request quote
—
ME31-16
Company Presentation 2026
AI MDT / 16ch Platform
The largest-channel sibling of the ME31-12 above - same guidance applies, just for an even larger vehicle or one with an unusually high number of camera positions. Not a realistic fit for standard patrol or light vehicles. Water rating: none published - in-cab recorder.
Request Quote
request quote
—
ME35-04/08
Company Presentation 2026
4/8ch AI MNVR
The IP-camera-only counterpart to the ME32/ME31 MDVR line above - an MNVR (network video recorder) takes purely IP cameras, no analog/AHD inputs at all. If a vehicle's cameras will all be IP-based (the same C62 family already priced, rather than the C60 AHD family), this is the more architecturally consistent choice over the mixed-input ME32/ME31 units. Pick 4 or 8 channels by camera count needed. Water rating: none published - in-cab recorder.
Request Quote
request quote
—
ME30-04
Company Presentation 2026
Basic 4ch MDVR
The 'no AI' option in the MDVR range - a plain 4-channel recorder with no face/DMS/ADAS processing at all. Cheaper, but it won't satisfy any requirement calling for driver-monitoring or collision-warning features, which this program's earlier requirements explicitly wanted. Only relevant for a vehicle that's genuinely just about recording footage with zero analytics.
Request Quote
request quote
—
8+4ch MHVR
Company Presentation 2026
Hybrid DVR (8 analog + 4 IP)
A hybrid recorder that takes both analog (AHD) and IP cameras on the same box - useful specifically if a vehicle already has analog cameras installed and IP cameras need adding without ripping out existing wiring or running two separate recorders. Choose this over a pure MDVR or MNVR only if that mixed-camera situation actually exists on a given vehicle.
Request Quote
request quote
—
8+8ch MHVR
Company Presentation 2026
Hybrid DVR (8 analog + 8 IP)
The larger sibling of the 8+4 hybrid above, with equal capacity for analog and IP cameras (8 of each). Same use case - mixed analog/IP camera vehicles - just for a vehicle with more total camera positions than the 8+4 covers.
Request Quote
request quote
—
Others (Licenses & Software) (2)
Platform and AI licenses. VSS connects units to remote viewing; the AI license ships bundled free with the main dashcams.
VSS-ME
Quote 17 Jul + PI + email 27 Jul
VSS Platform License
Not a device - the software subscription that connects a recorder to Howen's video-management server for remote live viewing, clip pulling, and event push. Without it, a unit just records locally with no remote visibility; with it, dispatch or command can see and pull footage off-vehicle. Every recorder and dashcam in the fleet needs one, so budget it per unit, not per vehicle (a vehicle with two recorders needs two licenses). Whether it's a one-time or recurring fee is still unconfirmed in writing - a negotiation point, not a buying one.
$15
per device
—
Hero-AL05-FDA / AL07-FDA
Quote 17 Jul x2
AI License (Face+DMS+ADAS)
The unlock for the face-recognition/DMS/ADAS features built into the camera hardware - without it, the unit still records plain video, but none of the AI overlays (drowsiness alerts, lane-departure warnings, face capture) run. It's already bundled free into both dashcam prices above (line shows $0 - Howen isn't charging for it separately on either the MC30-02H or ME40-02), so there's no separate purchase decision to make; it's listed only to confirm the AI features aren't a hidden extra cost.
Screens, dispatch terminals, sensors and add-ons not part of the camera-kit scope. Kept for reference; expand to view.
D8 DMS Camera (new design)
Company Presentation 2026
Driver Monitoring Camera
A standalone driver-monitoring camera doing the same job (fatigue, smoking, phone use, seatbelt, attendance detection) already bundled free into the MC30-02H and ME40-02's AI license above. Only worth buying separately if deploying on a recorder that doesn't already include DMS, or if the DMS camera needs to be positioned independently from the main dash unit rather than using the dashcam's own in-cab lens.
Request Quote
request quote
—
A7 ADAS Camera (new design)
Company Presentation 2026
Advanced Driver Assist Camera
A standalone ADAS camera (forward collision, lane departure, pedestrian warnings) - the same functions already included in the MC30-02H and ME40-02's bundled AI license via their built-in front camera. Same guidance as the D8 DMS camera above: only relevant as a separate purchase if deploying on hardware that doesn't already include ADAS.
Request Quote
request quote
—
Hero-CAN-01
Quote 17 Jul + PI
CANBUS Library License
A software unlock, not a physical part - it lets the recorder decode a specific vehicle's CANBUS traffic (real speed, RPM, odometer, fuel level, door status, depending on what the vehicle's bus exposes and which manufacturer library Howen has mapped). This overlaps in purpose with the OBD/CANBUS Reader listed under Accessories below - confirm with Howen whether that hardware reader is actually needed on top of this license, or whether the license alone through the recorder's built-in CAN port is sufficient. Buy it for real vehicle telemetry (not just GPS-derived speed) for driving-behavior or fuel-fraud analysis; skip it if GPS location and speed alone covers the requirement.
$27
per device
—
MDT AT5 V5
Company Presentation 2026
Android Taxi Dispatch Terminal
A rugged Android tablet for taxi dispatch, cashless fare payment, NFC/RFID driver ID, and passenger counting, with OIML/MID certification for fare-metering programs - genuinely useful if the deployment includes taxi-style fare/dispatch operations. It cannot currently be bought, though: Rocket's 27 Jul email confirmed production and quoting are suspended (component shortages, no timeline given). Don't plan around this until Howen lifts the suspension.
Request Quote
request quote
—
MDT AT5 V2
Company Presentation 2026
Android Dispatch Terminal (alt.)
An alternate, likely older tier of the same dispatch-tablet family as the AT5 V5 above. The production suspension mentioned for the V5 hasn't been separately confirmed for this variant, but given they're the same product line, assume the same restriction applies until Howen says otherwise.
Request Quote
request quote
—
Taxi Rear Passenger Screen
Company Presentation 2026
In-Cab Passenger Display
A screen facing the back seat for fare display, advertising, or trip status - a taxi commercial-experience feature with no security or evidentiary function. Only relevant if the program's taxi vehicles need a passenger-facing display for commercial reasons; otherwise skip it entirely.
Request Quote
request quote
—
Bus Passenger Info Display
Company Presentation 2026
Public Info Screen
A route/stop information screen for bus passengers, similar purpose to the taxi rear screen above but aimed at public transit riders rather than a single passenger. Not a security feature - only relevant if buses in the program double as public-facing transit vehicles needing passenger information displays.
Request Quote
request quote
—
People Counter Module
Company Presentation 2026
Passenger Counting Camera
Passenger counting was explicitly excluded from the dashcam requirements agreed on 19 Jul, and for good reason: Howen's own materials tie passenger counting to the full MDT dispatch-tablet solution (the AT5 series above), not a standalone camera add-on - and that MDT line is currently suspended anyway. Don't pursue this item; it doesn't fit as a simple accessory and the path to it is blocked regardless.
Request Quote
request quote
—
OBD/CANBUS Reader
Company Presentation 2026
Vehicle Diagnostics Reader
A physical device that taps the vehicle's OBD-II/CANBUS port - the hardware counterpart to the CANBUS Library License above (that's the software that decodes what this hardware reads). Ask Howen directly whether the ME40-02's built-in CAN port already covers this, or whether this separate reader is genuinely required in addition to the license; buying both without confirming risks paying twice for the same capability.
Request Quote
request quote
—
Fuel & Gas Sensor
Company Presentation 2026
Capacitive/Ultrasonic Fuel Sensor
An aftermarket sensor plumbed into the fuel tank to feed real fuel-level data to the recorder, used for detecting fuel theft or tracking consumption. A fleet-cost-management feature with no direct security function - relevant only if fuel fraud is an actual concern for these vehicles, otherwise skip it.
Request Quote
request quote
—
Weight / Load Sensor
Company Presentation 2026
Load Monitoring Sensor
Monitors cargo weight for trucks. Only relevant if the program includes cargo-carrying trucks whose load needs tracking or overload alerts; meaningless for patrol cars, taxis or passenger vehicles.
Request Quote
request quote
—
TPMS Sensor
Company Presentation 2026
Tire Pressure Monitoring
Tire pressure and temperature monitoring - a vehicle-maintenance and safety feature, unrelated to the security/surveillance mission. Worth considering only if fleet maintenance oversight, not just video/security, is part of what this program covers.
Request Quote
request quote
—
Door Sensor
Company Presentation 2026
Door Open/Close Sensor
Detects whether a door is open or closed - relevant for buses and taxis where door events matter (passenger safety, fare logic, or triggering a camera to record on door-open). Not useful for a standard patrol car with no passenger-door workflow to monitor.
Request Quote
request quote
—
Temp & Humidity Sensor
Company Presentation 2026
Cargo Condition Sensor
Monitors temperature and humidity inside a cargo area - relevant only for refrigerated or sensitive-cargo trucks. Irrelevant to passenger or patrol vehicles.
Request Quote
request quote
—
RFID/NFC Reader
Company Presentation 2026
Driver/Passenger ID Reader
Identifies a driver (or passenger, for fare payment) by tapping a card or tag - useful if the program wants to log who was driving a given vehicle at a given time, tying footage and events to a specific person rather than just a vehicle. Worth checking whether MOI wants that driver-accountability layer; if not, this is an unnecessary extra.
Request Quote
request quote
—
iButton Reader
Company Presentation 2026
Driver Authorization Reader
Does the same driver-identification job as the RFID/NFC reader above, but with an older contact-key technology instead of a tap card. Pick one or the other based on whatever ID/key system the deployment already uses elsewhere - no reason to buy both for the same purpose.
Request Quote
request quote
—
Panic Button
Company Presentation 2026
Emergency SOS Button
A physical button wired into the recorder's existing SOS input - both the MC30-02H and ME40-02 already have a panic-button input built in per their datasheets, so this is just the button itself, not new capability. Buy it only if officers or drivers actually need a manual panic trigger; if that input would otherwise go unused, there's no reason to add the button.
Request Quote
request quote
—
Fireproof Protective Enclosure
Company Presentation 2026
MDVR Crash-Survivable Housing
A fire-rated box around the recorder itself, so footage can potentially be recovered even if the vehicle burns after a serious crash - the vehicle equivalent of an aircraft's black box. Adds cost and installation complexity for a scenario that's low-probability for most patrol vehicles; a budget and risk-tolerance decision rather than a technical necessity, worth it mainly for higher-risk vehicles or where post-incident evidence assurance really matters.
Request Quote
request quote
—
Push-to-Talk Intercom
Company Presentation 2026
PTT Communication Module
A two-way voice/radio function tied into the recorder, letting dispatch talk through the vehicle's camera unit rather than a separate radio. Only useful if the program wants voice communication folded into the video system; skip it if the fleet already has its own radio network doing that job.
